Intrinsically Safe Series 'EX' liquid quality sensor for 1/2" pipe thread - WiFiEx


EX



W

  X H


Output

  R = XML RS232
  4 = 4...20 mA



Price: (for sensor + transmitter + battery + receiver)

From 2000.00 US$ (no cable cost, no barrier cost, no engineer installation cost)


Technical Data
Sensor:
Operating Temp: -20C to +49C
Housing Material: St. Steel
Threads: 1/2" pipe thread
IP rating: IP66
Transmitter:
Operating Temp: -20C to +49C
Housing Material: Plastic
IP rating: IP66
Peak RF: 0 dBm, 1mW
WiFi Frequency: 2.4 GHz
Data Rate: 250 kbs
Battery Pack:
Operating Temp: -20C to +49C
Housing Material: Stainless Steel
IP rating: IP66
Humidity: 98% permissible
Type: Lithium Thyonide Chloride
Life Time: Max 1.5 years, 19,000 mAhrs
  1 data transmission per 60 s
Receiver Module:
- Click above for a full description of the outputs that can be generated from the receiver module.
- The default output protocol is RS232, which can be read and viewed with the Hyper Terminal in windows and also with the most common data acquisition software packages such as Labview, Daisy, WonderWare, WinWedge and Excel.
- Other outputs can be ModBus or 4...20 mA
Identity:
Each sensor has a unique identity number in case multiple sensors are purchased.  The ID numbers can be customer specified.  As default, they be the serial number of the device, this way, there will never be conflicting identities on a system.

Certifications

IP66/X7

IECEx [Certificate]

ATEX [Certificate]

Mounting Instructions

1. Just before installing sensor onto the pipe, screw the battery pack in firmly to the transmitter housing (the clear part)

2. Mount the sensor mechanically as you would any other sensor on a pipe.

3. On the safe side, plug in the receiver module into the PLC or computer and start reading the data in whatever format you have.

4. The battery can be 'hot-swapped' in the field for a new battery if it does run out.

5. If you will NOT immediately use the encoder, do NOT connect the battery.  Only connect the battery right before using.

Dimensions
